• Allows use of the Tilton 900-series balance bar which utilizes needle bearings in all pivot points, eliminating the friction found in the stock Van Diemen balance bar assembly.
• Brake pedal, mounting brackets, and reservoir adapters are beautifully CNC machined from 6061-T6 billet aluminum.
• Brake pedal pivots on a needle bearing for smooth, consistent movement.
• Reuse your current foot pad.
• Except for some possible clearancing of the front bulkhead, the kit is completely bolt-on.
• Brake pedal and reservoir adapter are anodized for corrosion resistance.
• This system has been tested for many seasons, and results include a podium finish at the 2012 National Championship Runoffs.

KIT A upgrades the master cylinders only and retains the stock Van Diemen brake pedal and bias bar.

• Kit A includes:
  • Master cylinder mounting plates
  • Pushrod adapters
  • Reservoir adapter fittings
  • All spacers and hardware to install the Tilton 77-series master cylinders
• You supply:
  • Tilton 77-series master cylinders
  • Brake fluid reservoirs OBP or AP (we recommend AP # CP4709-12, shown installed on a car, below)

KIT B upgrades the brake pedal and bias bar only and retains the stock fixed master cylinders.

• Kit B includes:
  • Brake pedal
  • All spacers, bearings, and hardware to install the new brake pedal and Tilton 900-series bias bar

• You supply:
  • Tilton 900-series bias bar

KIT C upgrades the master cylinders, the brake pedal, and the bias bar.

• Kit C includes:
  • Brake pedal
  • Master cylinder mounting plates
  • Pushrod adapters
  • Reservoir adapter fittings
  • All spacers, bearings, and hardware to install the complete kit

• You supply:
  • Tilton 77-series master cylinders
  • Tilton 900-series bias bar
  • Brake fluid reservoirs OBP or AP (we recommend AP # CP4709-12, shown below)
